Nome
/ Name |
Breda Ba. 65 A80
"Nibbio" |
Carattestistiche/ Type |
Assaltatore
monoplano
monomotore |
Anno di Costruzione Year of constr. |
1935 |
Primo Volo/ First flight |
settembre 1935
pilota
Ambrogio Colombo |
Progettista/ Eng. |
Ing. Antonio
Parano Ing.
Giuseppe Panzeri |
Equipaggio n. /Crew |
1-2 |
Ap. Alare / mt. Span wings |
12,10 |
Lunghezza/ mt. Lenght |
9,30 |
Altezza/ mt. Height |
3,20 |
Sup. Alare mq / Wing area |
23,50 |
Motore -i / Power Plant-s |
1 Fiat A.80 RC41
da 100cv a
4100 mt |
Peso max / Max weight |
2950 kg. (3500
biposto) |
Peso a secco / Empty weight |
2400 kg. ( 2400
biposto) |
Carico utile / Loaded weights |
1000 kg. di bombe |
Armamento / Armament |
2 mitr. da 12,7
mm + 2 mitr.
da 7,7mm |
Vel.
max/ Max speed |
430 km/h ( 410
biposto) |
Tangenza prat. / |
8300 mt (max) |
Autonomia / Range |
550 km (1100
biposto) |
Produzione / Production |
263 esemplari
|
